For more information, inquire at info@lintrinsicsemi.com
Switch Products:
| Product | Config. | Insertion Loss | 1dB Bandwidth | Peak Power Handling (25C) | Average Power Handling (25C) | 10-90% Risetime | 0.1dB Settling Time | Package |
| LSI-001-A | SPDT | 0.6dB at 12GHz | 18GHz | >40W | <20W* | 40ns | 200ns | 4x4mm QFN |
| LSI-002-A | SPDT | 1dB at 40GHz | 55GHz | >5W | <2W* | 1ns | 13ns | Flip-chip 1.8×1.6mm die |
| LSI-002-D | SPDT | 1dB at 40GHz | 55GHz | 1W | <1W* | 1ns | 13ns | Flip-chip 1.8×1.6mm die |
| LSI-003-A | SP4T | 1.2dB at 18GHz | 20GHz | >4W | <4W* | 120ns | <1us | Flip-chip 1.6×1.25mm die |
*Estimated
Switch Driver Products:
| Product | Configuration | Voltage Range | Typical Switching Time | Package |
| LSI-004-4T | SP4T complementary outputs | -25V to +25V | 20ns | 1.35x1mm wirebondable die |
| LSI-004-8T | Configuration | -25V to +25V | 20ns | 2.26x1mm wirebondable die |
